Born in Rancagua, Chile, the 23rd of January 1967. Resident in
Sweden
since June 1976. Became Swedish citizen the 14th of February 1990.
Finished medicine studies at the Faculty of Medicine, Karolinska
Institutet, 12th of June 1992.
Has been teaching Anatomy at the Karolinska Institutet since
1989,
initially with a position at the former Department of Anatomy, and
then at the Department of Neuroscience.
Obtained a passing grade in the examinations at the Faculty of Medicine,
Karolinska Institute for a PhD degree in Neuroscience, 25th of April
1997.
Thesis title: Morphological and immunohistochemical studies on the
organisation of sacral motoneurons.
Finished internship at Huddinge hospital, 28th of February 1998.
Obtained authorization from the National Swedish Board of Health and
Welfare to practise the Medical Profession as a Physician, 7th of
April 1998.
Postdoctoral studies at the Department of Anatomy, Institute
of Basic Medical Science, Oslo, in collaboration with professor Ole Petter
Ottersen, 1999-2000.
Thesis
& Post Doctorate Program
Thesis
Morphological and immunohistochemical studies on the
organization of sacral motoneurons
THESIS ABSTRACT
The aim of this thesis was to study pre- and postsynaptic elements during
postnatal development and aging. Motoneurons from two adjacent sacral motor
nuclei in the cat spinal cord were investigated: the motoneurons innervating
intrinsic foot-sole muscles (dorsolateral motor nucleus; DLN) and the motoneurons
innervating striated perineal muscles (Onuf’s nucleus, ventrolateral motor
nucleus; VLN). Most of the work has focused on dendrites, since they constitute
>90% of the motoneuron’s receptive domain. The employed techniques have
been intracellular tracer labeling, indirect single- and double-staining
immunofluorescence, and pre- and post-embedding immunocytochemistry.
The establishment of VLN dendrites in a circumscribed rostro-caudally
oriented bundle takes place during the first two postnatal months and appears
to be closely linked to the occurrence of dendro-dendritic contacts. During
maturation a dramatic drop in the proportion of the dendritic membrane
area involved in this type of contacts was seen.
In the DLN, a postnatal remodeling of the dendrites was seen, including
a five-fold increase in total dendritic membrane area, changes in branching
pattern and a net decrease in number of branches per dendrite. Dendritic
growth/remodeling and neo-synaptogenesis were, however, also seen in aged
animals (15y), indicating that neurons and their connectivity are continuosly
“remodeled”.
Several stigmata of aging were present in the VLN and DLN neuropil
of older cats, as the increased frequency of dark-degenerating dendrites,
and the occurrence of “aberrant” dendrites with an irregular outline, increased
electron density of the dendroplasm and tighter packing of neurotubules.
Regarding presynaptic elements, the distribution and synaptic arrangement
of different transmitter identified inputs to the VLN and DLN was examined.
In adult animals, the descending bulbospinal serotoninergic pathway to
the VLN was of the same size-order as that to the DLN. Experimental lesions
(spinal cord transection at the lower thoracic level performed alone or
in combination with unilateral dorsal rhizotomy) revealed a dual supraspinal
and spinal origin for the substance P input to both nuclei. The contribution
of substance P to the innervation of the VLN and DLN was of the same magnitude,
although substance P-immunoreactive (IR) fibres of spinal origin were somewhat
more frequent in the VLN. In addition, the VLN received also a denser enkephalinergic
innervation than the DLN. Thirty-four percent of the boutons apposing VLN
dendrites were immunoreactive for glutamate, while fourty-nine percent
of all boutons were immunoreactive for GABA and/or glycine. The proportions
of boutons immunoreactive to glutamate and GABA and/or glycine were rather
similar in the VLN and DLN. However, the proportion of boutons single labeled
for glycine was greater in the DLN than in the VLN.
Substance P-IR boutons had a rather even distribution throughout the
dendritic trees of the VLN, apposing both thin distal branches and thick
proximal dendrites, while TRH and enkephalin were preferentially located
in apposition to more proximal dendritic domains. A frequent fining in
the VLN was that one axonal bouton could be seen in synaptic contact with
2-3 dendrites. This divergence of the input at the terminal level was commonly
seen among substance P-IR, enkephalin-IR and glutamate-IR boutons, as well
as among boutons immunoreactive to GABA and/or glycine. A similar arrangement
was not observed for TRH, indicating that the supraspinal input to the
VLN might rather be a point-to-point system with each axonal bouton acting
on a single postsynaptic element.
In the VLN, differences were seen between animals of different ages
in the distribution of amino acid inputs, in particular a smaller number
of boutons immunoreactive to glutamate was observed in the older animals.
Since no such differences were present in the DLN, this may reflect interindividual
variations, changes in the endocrine system and/or differences with age.
In the spinal cord of aged rats, axonal profiles showing aging-related
morphological changes (accumulation of residual bodies, dystrophy and/or
degeneration) were often enriched with immunoreactivity to glutathione
(GSH). Since GSH is a scavenger for H2O2, this suggests that oxidative
stress may be relevant for axon degeneration during aging. In addition,
about sixty-five percent of the GSH enriched axons with aging-related changes
contained also glutamate-immunoreactivity. Aging-related degeneration could
not be verified for axons containing glycine and/or GABA. This implies
that excitatory pathways may be more susceptible to aging-related changes
than inhibitory pathways.
Keywords: spinal cord, dendrites, synaptic input, aging.
IBSN 91-628-2403-1.
Post
Doctorate Program
ALS-resistant and ALS-vulnerable motoneurons - immunohistochemical
studies
GENERAL BACKGROUND
The ventrolateral nucleus (VLN), considered to be the feline homologue
to Onuf’s nucleus in man (Onuf, 1900), is located in the ventral horn at
the S1/S2 spinal segment levels. VLN motoneurons innervate striated perineal
muscles, as the sphincter urethrae, the sphincter ani externus, the bulbospongiosus
and the ischiocavernosus muscles (e.g. Sato et al., 1978; Kuzuhara et al.,
1980). Dorsolateral to the VLN is the somatic motor nucleus (dorsolateral
nucleus; DLN) whose motoneurons innervate the intrinsic muscles of the
foot sole, i.e. the flexors digitorum brevis and longus, and the plantaris
muscle (e.g. Egger et al., 1980; Ulfhake and Kellerth, 1983).
In contrast to DLN motoneurons, VLN motoneurons are strongly related
with autonomic spinal cord centers, as the sacral parasympathetic nucleus
(SPN) that supplies the smooth muscles of the bladder and rectum. The dense
aminergic and peptidergic innervation of the VLN is also closer to the
innervation pattern of the SPN than to that of the DLN (Blok and Holstege,
1996). The similarities in afferent input between the SPN and VLN may be
a means to co-ordinate the activity pattern of somatic and visceral structures
in complex functions such as micturition, defecation and copulatory behaviour
(Blok and Holstege, 1996).
The predisposition of VLN motoneurons to certain degenerative diseases
differs from that seen in adjacent lumbosacral motor nuclei, such as the
DLN, and appears instead to be related to the selective vulnerability of
autonomic spinal cord centers. Thus, in amyotrophic lateral sclerosis VLN
motoneurons are more resistant than nearby located motoneurons (as in the
DLN) that degenerate/die. This implicates that incontinence is a rather
late symptom among ALS-patients (Mannen et al., 1977). VLN motoneurons
are however extensively affected in for example Shy-Drager disease, that
affects more selectively the autonomic nervous system (Sung et al., 1979).
Another specific characteristic of the VLN, that has extensively been
studied in its homologue in the rat, is the androgen-dependent sexual dimorphism
in terms of cells size and number (see Breedlove, 1986; Arnold, 1992).
This sexual dimorphism is established during early development and is believed
to be due to the fact that VLN motoneurons supply perineal muscles that
are of importance in male reproduction, but that are rudimentary/lacking
in females.
Against this background, comparative studies between the VLN, a sexually
dimorphic motor nucleus that is intimately related to the autonomic nervous
system, and the DLN, a presumably non-dimorphic, purely somatic motor nucleus,
appear to be of interest.
SPECIFIC AIMS
The aim of this project is to study motoneurons located in two adjacent
motor nuclei in the sacral segments of the spinal cord, VLN and DLN. There
is both indirect and direct evidence that glutamate, the most important
excitatory neurotransmitter in the nervous system, may be involved in the
pathology of ALS. It is however not known if the disturbances in glutamatergic
signal transmission that have been shown are a part of the primary process
or if they represent final stages of injury following several steps that
may have caused alterations in neuron metabolism. The described model system
(VLN/DLN) appears to be suitable for further studies of, amongst others,
the molecular organization and development of glutamatergic synapses. The
aims would be to investigate the cause(s) of the relative resistance of
VLN motoneurons to ALS, in comparison to the notorious vulnerability of
DLN motoneurons.
One mechanism suggested to induce degenerative changes during
aging is cellular accumulation of free radicals (“free radical theory of
aging”; e.g. review by Harman, 1981). Thus, aging-related degeneration
may, at least in part, be explained by a changed cellular redox status
with decreased antioxidant capacity and/or an increased oxidative stress.
Since a previous study showed increased glutathione levels in the aged
rat lumbar motor nuclei (Ramírez-León et al., 1999), we now
examine the distribution of free radical scavengers in the VLN/DLN.
Conventional postembedding immunohistochemistry of freeze-substituted
tissue permits a precise localization at the ultrastructural level of antigens
otherwise not detectable. We use this technique to study glutamatergic
synapses on VLN/DLN motoneurons, looking at the synaptic arrangement and
degree of expression of glutamate receptors. In addition, we examine the
pre- and postsynaptic distribution of glutathione and superoxide dismutase
in the VLN/DLN of young adult and aged animals, as well as the possible
presence of these scavengers in glutamatergic pathways. The work is done
in collaboration with professor Ole Petter Ottersen, Department of Anatomy,
Institute of Basic Medical Sciences, Oslo.
References
Arnold, A.P. (1992) Exp. Gerontol. 27:99-110.
Blok, B.F.M., Holstege, G. (1996) Progress in Brain Res. 107:113-126.
Breedlove, S.M. (1986) J. Neurobiol. 17:157-176.
Egger, M.D. et al. (1980) J. Physiol. 306: 349-363.
Goldstein, L.A., Sengelaub, D.R. (1994) J. Neurobiol. 25:878-892.
Harman, D. (1981) Proc. Natl. Acad. Sci. USA 78:7124-7128.
Hays, T.C. et al. (1996) Dev. Brain Res. 91:20-28.
Kuzuhara, S. et al. (1980) Neurosci. Lett. 16:125-130.
Mannen, T. et al. (1977) J. Neurol. Neurosurg. Psychiatry 40:464-469.
Onuf, B. (1900) Arch. Neurol. Psychopathol. 3:387-412.
Ramírez-León, V. et al. (1999) Europ. J. Neurosci. 11:2935-2948.
Sato, M. et al. (1978) Brain Res. 140:149-154.
Sung, J.H. et al. (1979) J. Neuropathol. Exp. Neurol. 38:353-368.
Ulfhake, B., Kellerth, J.-O. (1983) Brain Res. 264:1-19.
Abstracts
Changes of dendritic anatomy of hind-limb motoneurons
in the aged cat
Ramírez, V., Stuart, L. and Ulfhake, B.
European Journal of Neuroscience, ENA Abstracts 41.16. 1989
Maturation of the dendritic tree anatomy in cat
foot sole motoneurons during postnatal development
Ramírez, V. and Ulfhake, B.
European Journal of Neuroscience, ENA Abstracts 3165. 1990
. Serotonin-, CGRP-, Galanin-, TRH- and GAD-like
immunoreactive fibers and terminals in the aged rat spinal cord
Johnson, H., Ulfhake, B., Hökfelt, T. and Ramírez, V
European Journal of Neuroscience, ENA Abstracts 1362.1990
Age related changes in dendritic branching probabilities
of motoneurons (MNs) supplying the intrinsic foot sole muscles
Ramírez, V., Burke, R.E., Mark, W.B. and Ulfhake, B.
European Journal of Neuroscience, ENA Abstracts 1362. 1991
Membrane properties and HRP anatomy of cat soleus
alpha-motoneurons (MNs)
Örnung, G., Cullheim, S., Gollvik, L., Ramírez, V.
and Ulfhake, B.
European Journal of Neuroscience, ENA Abstracts 4343.1991
Distribution of enkephalin-like immunoreactivity
in cat and monkey spinal cord with special reference to the descendig 5-hydroxytryptamine
bulbospinal pathway.
Cullheim, S., Arvidsson, U., Ulfhake, B., Ramírez, V.,
Luppi, P.-H., Kitahama, K., Jouvet, M., Terenius, L. and Hökfelt,
T.
European Journal of Neuroscience, ENA Abstracts 2253.1991
Distribution of enkephalin in cat and monkey spinal
cord and cat medulla oblongata.
Arvidsson, U., Ulfhake, B., Cullheim, S., Ramírez, V.,
Luppi, P.-H., Kitahama, K., Jouvet, M., Terenius, L. and Hökfelt,
T.
Third IBRO World Congress of Neuroscience, Montréal, Canada.
1991
Innervation pattern of GABA-IR axonal boutons
in the motor nuclei of the cat S1 spinal segment.
Ramírez-León, V. and Ulfhake, B.
European Journal of Neuroscience, ENA Abstracts 2205. 1992
Peptidergic and GABAergic innervation of the ventrolateral
dendritic bundle in the cat S1 spinal cord segment.
Ramírez-León, V., Hökfelt, T and Ulfhake,
B.
Society for Neuroscience Annual Meeting, Washington D.C., abstract
402.7. 1993
Increased levels of glutathione in neurochemically
identified fibre systems in the aged rat lumbar motor nuclei.
Ramírez-León, V., Kullberg, S., Hjelle, O.P.,
Ottersen, O.P. and Ulfhake, B.
Society for Neuroscience Annual Meeting, Miami, abstract 532.1.1999
Quantitative immunogold analysis suggests different
modes of expression of AMPA and NMDA receptors in hippocampal synapses.
Rinvik, E., Takumi, Y., Ramírez-León, V. and Ottersen,
O.P.
Society for Neuroscience Annual Meeting, Miami, abstract 593.15. 1999
Full
Publication List
Modes of glutamate receptor expression in postsynaptic
specializations.
Ramírez-León, V., Utvik, J.K., Takumi, Y., Rinvik, E.,
and Ottersen O.P. (2000)
In Cavalheiro, E.A., Schoepp, D.D., Turski, L. (eds.), Advances in
Excitatory Amino Acid Research II. IOS Press, Amsterdam. In press.
Increased
glutathione levels in neurochemically identified fibre systems in the aged
rat lumbar motor nuclei.
Ramirez-Leon V, Kullberg S, Hjelle OP, Ottersen OP, Ulfhake B
Eur J Neurosci 1999 Aug;11(8):2935-48. PubMed,
Synergy
Different modes of expression of AMPA and NMDA
receptors in hippocampal synapses.
Takumi Y, Ramirez-Leon V, Laake P, Rinvik E, Ottersen OP
Nat Neurosci 1999 Jul;2(7):618-24. PubMed
Phosphate activated glutaminase is concentrated
in mitochondria of sensory hair cells in rat inner ear: a high resolution
immunogold study.
Takumi Y, Matsubara A, Laake JH, Ramirez-Leon V, Roberg B, Torgner
I, Kvamme E, Usami S, Ottersen OP
J Neurocytol 1999 Mar;28(3):223-37. PubMed
Decreased
axosomatic input to motoneurons and astrogliosis in the spinal cord of aged
rats.
Kullberg S, Ramirez-Leon V, Johnson H, Ulfhake B
J Gerontol A Biol Sci Med Sci 1998 Sep;53(5):B369-79. PubMed
Serotoninergic,
peptidergic and GABAergic innervation of the ventrolateral and dorsolateral
motor nuclei in the cat S1/S2 segments:
an
immunofluorescence study.
Published erratum appears in J Chem Neuroanat 1994 Oct;7(4):289-98
Ramirez-Leon V, Ulfhake B, Arvidsson U, Verhofstad AA, Visser TJ, Hokfelt
T
J Chem Neuroanat 1994 Jul;7(1-2):87-103. PubMed.
Enkephalin-,
thyrotropin-releasing hormone- and substance P-immunoreactive axonal innervation
of the
ventrolateral
dendritic bundle in the cat sacral spinal cord: an ultrastructural study.
Ramirez-Leon V, Hokfelt T, Cuello AC, Visser TJ, Ulfhake B
J Chem Neuroanat 1994 Oct;7(4):203-15. PubMed
GABA-like
immunoreactive innervation and dendro-dendritic contacts in the ventrolateral
dendritic bundle
in
the cat S1 spinal cord segment: an electron microscopic study.
Ramirez-Leon V, Ulfhake B
Exp Brain Res 1993;97(1):1-12. PubMed
Distribution
of enkephalin and its relation to serotonin in cat and monkey spinal cord
and brain stem.
Arvidsson U, Cullheim S, Ulfhake B, Ramirez V, Dagerlind A, Luppi PH,
Kitahama K, Jouvet M, Terenius L, Aman K, et al
Synapse 1992 Jun;11(2):85-104. PubMed
Distribution
of calbindin D28k-like immunoreactivity (LI) in the monkey ventral horn: do
Renshaw cells contain calbindin D28k-LI?
Arvidsson U, Ulfhake B, Cullheim S, Ramirez V, Shupliakov O, Hokfelt T
J Neurosci 1992 Mar;12(3):718-28. PubMed
Anatomy
of dendrites in motoneurons supplying the intrinsic muscles of the foot sole
in the aged cat: evidence for dendritic growth and neo-synaptogenesis.
Ramirez V, Ulfhake B
J Comp Neurol 1992 Feb 1;316(1):1-16. PubMed
Postnatal
development of cat hind limb motoneurons supplying the intrinsic muscles of
the foot sole.
Ramirez V, Ulfhake B
Brain Res Dev Brain Res 1991 Oct 21;62(2):189-202. PubMed
|
